40-Meter 5-Section KCP Concrete Pump KCP40ZX5170
(In stock)
| Product Name | 40-Meter 5-Section KCP Concrete Pump KCP40ZX5170 |
| Part Number | KCP40ZX5170 |
| Category | Pumps |
| Manufacturer | KCP Concrete Pumps |
| Country Of Origin | Korea |
Boom Specifications
| Specification | Value |
|---|---|
| Vertical Height | 39.6 m (130’) |
| Horizontal Reach | 35.6 m (116’11”) |
| Reach from Front of Truck | 31.6 m (103’8”) |
| Unfolding Height | 7.91 m (25’11”) |
| End Hose Length | 3.5 m (11’6”) |
| Delivery Line Diameter | 125 mm (5”) |
| Boom Rotation | 370° |
| Section Articulation | 92° / 186° / 240° / 180° / 245° |
| Outrigger Spread – Front | 6.25 m (20’4”) |
| Outrigger Spread – Rear | 8.1 m (26’7”) |
| Max. Outrigger Weight | 25,000 kg (55,116 lbs) |
Pump Specifications
| Specification | Value |
|---|---|
| Maximum Output | 170 m³/h (222 yd³/h) |
| Concrete Pressure | 63 bar (914 psi) |
| Hydraulic Pump | Rexroth A11VLO260 |
| Concrete Cylinder Size | Ø230 x 2,100 mm (9” x 83”) |
| Cycling System | Hydraulic with manual overrides |
| Max. Aggregate Size | 40 mm (1.5”) |
| Hopper Capacity | 0.6 m³ (21 ft³) |
