46-Meter KCP Concrete Pump KCP46ZX5170HP
(In stock)
| Product Name | 46-Meter KCP Concrete Pump KCP46ZX5170HP |
| Part Number | KCP46ZX5170HP |
| Category | Pumps |
| Manufacturer | KCP Concrete Pumps |
| Country Of Origin | Korea |
Boom Specifications
| Specification | Value |
|---|---|
| Vertical Height | 45 m (148’1”) |
| Horizontal Reach | 40.9 m (131’4”) |
| Reach from Front of Truck | 38.6 m (120’10”) |
| Unfolding Height | 8.9 m (31’2”) |
| End Hose Length | 3.5 m (11’6”) |
| Delivery Line Diameter | 125 mm (5”) |
| Boom Rotation | 370° |
| Section Articulation Angles | 92° / 180° / 225° / 180° / 210° |
| Outrigger Spread – Front | 8.8 m (28’11”) |
| Outrigger Spread – Rear | 9.5 m (31’2”) |
| Proportional Beam | Yes |
| Max. Outrigger Weight | 29,000 kg (63,934 lbs) |
Pump Specifications
| Specification | Value |
|---|---|
| Maximum Output | 170 m³/h (222 yd³/h) |
| Concrete Pressure | 95 bar (1,377 psi) |
| Hydraulic Pump | Rexroth A20VL0190 |
| Concrete Cylinder Size | Ø230 x 2,100 mm (9” x 83”) |
| Cycling System | Hydraulic with manual overrides |
| Max. Aggregate Size | 40 mm (1.5”) |
| Hopper Capacity | 0.6 m³ (21 ft³) |
