PROGRAMMABLE I/O
(In stock)
| Product Name | PROGRAMMABLE I/O |
| Part Number | GN-9372 |
| Category | Network Communication |
| Brand | CREVIS |
| Country of Origin | South Korea |
| Material | High-grade Plastic |
Programmable Specification
| Category | Details |
|---|---|
| Programming | CoDeSys V3.5.11.3 |
| Program Memory | 16 MBytes |
| Data Memory | 16 MBytes |
| I/O Input | %IW0 ~ %IW2047 (2048 words) |
| I/O Output | %QW0 ~ %QW2047 (2048 words) |
| Memory | %MW0 ~ %MW8191 (8192 words) |
| Non-Volatile Memory | 32 KBytes (Retain: 16 KBytes, Flag: 16 KBytes) |
| Run-Time System | Multiple PLC Tasks |
| Programming Languages | IEC 61131-3 (LD, IL, ST, FBD, SFC) |
| OPC-Server | DA |
| Online Change | Supporting |
| Source Upload/Download | Supporting |
| File Transmit | Supporting |
| Breakpoint | Supporting |
| Webvisualization | Not Supporting |
| RTC | Retain Time: < 15 days, Accuracy: < 2 min/month |
| Max. Task | 10 |
| Max. Cycle Task | 10 |
| Max. Status Task | 10 |
| Process Time | 7 µsec (90 Instructions) |
Interface Specification
| Category | Details |
|---|---|
| Adapter Type | Master & Slave Node (Modbus TCP, Modbus RTU) |
| Max. Expansion Module | 63 Slots |
| Max. Data Size | Max. 128 Byte each slot (Input+Output) |
| Max. Nodes | Limited by Ethernet Specification |
| Baud Rate | 10/100 Mbps, Auto-negotiation, Full Duplex |
| Ethernet Interface | RJ-45 socket * 2 pcs |
| Ethernet Protocol | Modbus/TCP, Modbus/UDP, SNTP, HTTP, DHCP/BOOTP, OPC-server |
| Max. Socket | 24 (UDP: 8, TCP: 16, TCP_LISTEN: 10) |
| Serial Interface | RS232/RS485 2-port (supports Touch Panel) |
| Serial Protocol | Modbus/RTU / Baud Rate: 2400~115200 bps (Default: 115200 bps) |
| Indicator | 6 LEDs (Module Status, Network Status, PLC Status, I/O Module Status, etc.) |
General Specification
| Category | Details |
|---|---|
| UL System Power | Supply Voltage: 24 Vdc nominal, Class 2 |
| System Power | Supply Voltage: 15~30 Vdc, Protection: Current Limit, Reverse Polarity |
| Power Dissipation | 110 mA typical @ 24 Vdc |
| Current for I/O Module | 1.5 A @ 5 Vdc |
| Isolation | System Power to Logic: Non-isolated, I/O Driver: Isolated |
| Field Power | Supply Voltage: 24 Vdc typical (Max: 30 Vdc) |
| Max. Current (Field) | DC 10 A Max. |
| Weight | 167 g |
| Module Size | 54 mm x 99 mm x 70 mm |
