Rotary Vane Vacuum Pump
(In stock)
| Product Name | Rotary Vane Vacuum Pump |
| Model Number | SVO-060, SVO-100 |
| Brand | DOOVAC |
| Category | Oil-Circulated Rotary Vane Vacuum Pumps |
| Country of Origin | South Korea |
| Material | Cast iron housing, carbon composite vanes, oil-resistant seals. |
| Applications | Vacuum packaging, food processing, laboratory equipment, medical instruments, vacuum molding, vacuum drying, and vacuum consolidation. |
| Technical Data | SVO-060 | SVO-100 | ||
|---|---|---|---|---|
| Nominal Displacment | 50Hz | ℓ/min | 50 | 85 |
| Nominal Displacment | 60Hz | ℓ/min | 60 | 100 |
| Ultimate Pressure | - | mbar | 2 | 2 |
| Motor Version-3 | - | V | - | - |
| Motor Version-1 | 50Hz | V | 110/220 | 110/200 |
| Nominal Motor Rating-3 | - | kW | - | - |
| Nominal Motor Rating-1 | - | kW | 0.2 | 0.25 |
| Nominal Motor Speed | 50Hz | min-1 | 1420 | 1420 |
| Nominal Motor Speed | 60Hz | min-1 | 1700 | 1700 |
| Sound Level | - | dB(A) | 50 | 52 |
| Water Vapour Tolerance Max | - | mbar | - | - |
| Water Vapour Capacity | - | ℓ/h | - | - |
| Operating Temperature Ambient | - | °C | 40 | 40 |
| Oil Filling | - | liter | 0.1 | 0.1 |
| Weight Appox | - | kg | 12 | |
